Industrial Automation using Ladder Logic PLC Programming
Project Overview
This project involves developing Programmable Logic Controller (PLC) code using Ladder Logic in RSLogix 500 for some common industrial automation scenarios. The project focuses on simulating and implementing common automation tasks encountered in manufacturing, material handling, and process industries.
Tech Stack
- Ladder Logic for programming.
- RSLogix 500 for code development.
- RSLogix Emulate 500 for code debugging and validation.
Automation Scenarios Implemented
- Digital Control Logic - Code to control the pressure in a compressor.
- Digital Filling Station - Code to automate a filling station involving conveyor, hoppers, sensors and more.
- Digital Rotameter - Code to measure fluid flow in a pipeline.
- Hourmeter - Code to track runtime of a host plant.
- Inventory Management - Code to track inventory.
- Multiposition Servo Application - Code to operate a servo system.
Methodology
- PLC Programming in RSLogix 500
- Designed Ladder Logic programs with rung-based control logic using inputs and outputs.
- Simulation & Testing in RSLogix Emulate 500
- Debugged and validated program execution using RSLogix Emulate 500, simulating real-world conditions.
